Battery Operated Automatic Watering Sprinkler System

TYPE 1

With this programmable watering timer, no more soggy lawns or dead plants in garden because of your forgetfulness.

Features:
[Timed Watering] Watering duration can be set from 1 minute to 300 minutes; watering frequency can be set from every 6 or 12 hours up to every 7 days.
[2 Outlets] Each port can be set independently. Manual bypass allows you to use faucet instantly without interrupting your set program.
[Digital Display] Large digital screen and legible digits ensure good visiblity in low-light area or even in darkness.
[Weatherproof] Waterproof shell enables you to use it outdoors, no worry of rainy days.
[User-Friendly] Easy to use and set without complicated installation and operation. Simply twist the knob and press the button, that’s it!
[Reliable Quality] Solid metal faucet connection is more tight and durable than ever. Improved inner pipe and solenoid valve make no more leaking.

Note:
*Batteries are not included.
*When battery is first connected, it takes up to 1 minute for the battery indicator to assess the battery strength.

Improvements:
1. Plastic faucet connection is replaced with a solid metal one. → to avoid the faucet connection loosing from the timer caused by sudden water pressure.
2. Inner pipe and solenoid valve are modified. → effectively solves the problem of failed programmed schedules due to the leaking pipe.

Specifications:
Color: Green
Material: ABS, Metal
Faucet Connection: US / EU(Optional)
*EU Same with UK
Maximum Operating Pressure: 80psi for irrigation use only
Timer Inlet: 3/4″ female hose thread
Timer Outlet: 3/4″ male hose thread
Diameter of Faucet: 27mm(US); 20mm(EU/UK)
Hose Connection: 14mm-Suitable for all known plug-in system
Working Pressure: 3-8bar
Water Temperature: 0℃~40℃
Watering Duration: adjustable 1~300 minutes
Frequency: adjustable 6 hours, 12 hours, 1 day~7 days
Power Supply: 2 * AA Alkaline Batteries(not included)
Item Size: 14.5*13.2*5.5cm / 5.7*5.19*2.16in
Package Size: 14.6*9.4*4.2cm / 5.74*3.7*1.65in
Item Weight: 424g / 14.95oz
Package Weight: 447g / 15.76oz(US); 452g / 15.94oz(EU/UK)

Button setting instructions：
AUTO: Timer waters according to your customized schedule
SET CLOCK: Set the time of day
START TIME: Select what time you would like watering to START
HOW LONG: Determine how long to water
HOW OFTEN: Choose how often you will water
OFF: Turn off all watering

Packing List:
1 * Water Timer(batteries not included)
1 * Filter
2 * Hose Connector
1 * User Manual(English)

Specifications:
Material: ABS + Copper
Color: Green
Faucet Connection: US / EU / UK (optional)
Diameter of Faucet: 27mm(US); 20mm(EU / UK)
Hose Connection: 14mm(Suitable for all known plug-in system)
Working Pressure: 25-100psi
Water Temperature: 0℃~40℃
Power Supply: 2 x 1.5V AA Alkaline Batteries (not included)
Watering Duration: adjustable 1~300 minutes
Frequency: adjustable 6 hours, 12 hours, 1 day~7 days
Item Size: 16*10*4.5cm / 6.3*3.9*1.8in
Package Weight: 379g / 13.37oz
Packege Size: 16.6*11*7cm / 6.5*4.3*2.8in

Button setting instructions：
AUTO: Timer waters according to your customized schedule
SET CLOCK: Set the time of day
START TIME: Select what time you would like watering to START
HOW LONG: Determine how long to water
HOW OFTEN: Choose how often you will water
OFF: Turn off all watering

Note:
Please allow 1-3mm differs due to manual measurement.
Due to the different display and different light, the picture may not show the actual color of the item. Thanks for your understanding.

Package List:
1 * Automatic Water Timer with Filter & Connection
